UCWFC203 Bearing | 17mm 4-Bolt Flange Bearing

UCWFC203 bearing is a 17mm bore four-bolt normal-duty flange bearing that utilizes set screws to secure to a 17mm shaft and has an metric based housing. UCWFC203 flange cartridge bearings are designed for circumstances where the bearing is mounted to a surface that is perpendicular to the shaft axis. Our superior UCWFC203 bearing with a 17mm bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UCWFC203 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, relubricating capabilities, and strategically placed set screws. UCWFC203 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UCWFC203 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UCWFC203 bearings, and we will be happy to assist you!

UCWFC203 Bearing Dimensions

• Part #: UCWFC203
• Shaft Diameter (d): 17mm
• Dimension (A): 90.0mm
• Dimension (P): 70.0mm
• Dimension (E): 49.5mm
• Dimension (I): 10.0mm
• Dimension (S): 10.0mm
• Dimension (J): 4.0mm
• Dimension (K): 5.0mm
• Dimension (G): 19.0mm
• Dimension (F): 55.0mm
• Dimension (Z): 25.9mm
• Dimension (Bi): 27.4mm
• Dimension (N): 10.0mm
• Dimension (M): 15.9mm
• Bolt Used: M8
• Dynamic Load Rating (kN): 9.55
• Static Load Rating (kN): 4.78
• Bearing Insert: UCW 203
• Housing Number: WFC 203
• Weight (kg): 0.6
