W0X Bearing | V-Guide Wheel Roller Bearing
Login to Request a Quote
The W0X v-guide wheel roller bearing is a modern engineering miracle for effective long-term linear motion requirements. V-guide wheel bearings offer the ultimate design flexibility for virtually any guided motion application. Having a 90-degree angle, the v-bearing creates a natural wiping action while also clearing debris from the system. W0X bearings are utilized in automation, woodworking, printing, packaging, and textile applications. The W0X bearing features special stainless steel and NBR shield/ seals for protection, keeping the internal lubricant in while unwanted debris is out; this bearing is fantastic for general purpose uses and factory floor conditions. For more information or a quote on W0X bearings and accessories, please get in touch with our customer support team, and we will be happy to assist you!
W0X V-Guide Bearing Dimensions
- Part #: W0X
- Protection: Seal/ Shield
- Wheel Material: 52100 Steel
- Ball Retainer Material: Nylon 6,6
- Shield Material: 300 Stainless Steel
- Seal Material: NBR
- Grease Type: Shell Alvania EP2
- Temperature Range (°F): -22 to +212
- Outside Diameter (D): 0.584"
- Width (W): 0.250"
- Bore Size (B): 0.1575" +0.0000" /-0.0003"
- Vee Radius Inside (VRI): 0.234"
- Vee Radius Outside (VRO): 0.359"
- Weight (g): 5.1
- Part #: W0X
- Protection: Seal/ Shield
- Wheel Material: 52100 Steel
- Ball Retainer Material: Nylon 6,6
- Shield Material: 300 Stainless Steel
- Seal Material: NBR
- Grease Type: Shell Alvania EP2
- Temperature Range (°F): -22 to +212
- Outside Diameter (D): 0.584"
- Width (W): 0.250"
- Bore Size (B): 0.1875" +0.0000" /-0.0003"
- Vee Radius Inside (VRI): 0.234"
- Vee Radius Outside (VRO): 0.359"
- Weight (g): 5.1
