Roller Chain > Roller Chain by Size > ANSI 50 Roller Chain 5/8 Pitch
Economy Plus #50 Nickel Plated Roller Chain - 10ft Box
Note:
Custom Cut to Length Chain Also Available
SKU: 50-NICKEL-PLATED-ROLLER-CHAIN
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
Economy Plus #50 Nickel Plated Roller Chain - 10ft Box Features
Economy Plus #50 Nickel Plated Roller Chain - 10ft Box Specifications
This #50 nickel plated roller chain is a durable and good quality roller chain that fully meets all ANSI Standards. Nickel plated roller chain is good in humid or slightly corrosive environments where normal roller chain tends to rust easily. The Economy Plus #50 nickel plated roller chain features parts that have been nickel plated evenly and fully which eliminates stress cracking, unwanted wear, and easy corrosion. Additionally, this chain is just as strong as the standard carbon steel roller chain and will work on the same sprockets. #50 nickel plated roller chain is commonly supplied in 10ft boxes including one connecting link in each box. However we can supply this chain on larger length reels and even custom lengths to meet your applications exact needs. We also offer nickel plated attachments and a full line of high quality ANSI #50 sprockets.
Dimensions:
Phone: (407) 347-3519
Email:sales@usarollerchain.com
Dimensions:
- Part Number: #50NP
- Tensile Strength: 6,100 LBS
- Pitch (P): 0.625"
- Roller Width (W): 0.375"
- Roller Diameter (D): 0.400"
- Chain Overall Width (F): 0.790"
- Overall Width Of Connecting Link: 0.850"
- Link Plate Height (H): 0.594"
- Link Plate Thickness (T): 0.079"
- Pin Diameter (E): 0.200"
- Weight Per Foot: 0.68 LBS
Phone: (407) 347-3519
Email:
- Part Number: #50NP
- Tensile Strength: 6,100 LBS
- Pitch (P): 0.625"
- Roller Width (W): 0.375"
- Roller Diameter (D): 0.400"
- Chain Overall Width (F): 0.790"
- Overall Width Of Connecting Link: 0.850"
- Link Plate Height (H): 0.594"
- Link Plate Thickness (T): 0.079"
- Pin Diameter (E): 0.200"
- Weight Per Foot: 0.68 LBS
