Premium #60 DHA Roller Chain

Roller Chain > Roller Chain by Size > #60 Roller Chain

Premium #60 DHA Roller Chain

Note: Custom Cut to Length Chain Also Available
SKU: 60-DHA-ROLLER-CHAIN
Item is in stockOnly 0 left in stockItem is out of stock Item is unavailable

Login to Request a Quote

<p>Don’t see what you need?</p>

Don’t see what you need?

Call us

Buy it With:

 [{"variant_id":"51714690482543" , "metafield_value":""}]
Premium #60 DHA Roller Chain Features
Premium #60 DHA Roller Chain Specifications
#60 DHA Roller Chain is an ultra high performance, premium ANSI roller chain that is engineered and manufactured for ultimate life, performance, and strength. DHA Series roller chain shows the most extended performances in applications that are exposed to dust, and harsh working environments versus a standard roller chain. This roller chain features a pin with a hardened layer of chromium carbide on the pins, which provides excellent resistance to corrosion and extreme hardness. #60 DHA chain will run on standard #60 roller chain sprockets due to the precise ANSI Standard manufacturing of the chain. For more information or to get a quote on DHA chain please contact us and we will be happy to assist you!

Dimensions:
Premium #60 DHA Roller Chain
  • Chain #: 60 DHA
  • Pitch (P): 0.750"
  • Roller Link Width (W): 0.500"
  • Roller Diameter (D): 0.469"
  • Pin Diameter (O): 0.235"
  • Pin Length (E): 1.000"
  • CL Pin Length (F): 1.059"
  • Plate Thickness (T): 0.094"
  • Plate Height (H): 0.713"
  • Tensile Strength: 9,900 LBS
  • Working Load Rating: 2,090 LBS
  • Weight Per Foot: 0.966 LBS


Pin Construction:
Premium #60 DHA Roller Chain


Comparison Of Properties:
Premium #60 DHA Roller Chain
Premium #60 DHA Roller Chain


Wear Resistance Comparison:
Premium #60 DHA Roller Chain


Phone: (407) 347-3519
Email: sales@usarollerchain.com

See What All We Offer "Here"!
  • Chain #: 60 DHA
  • Pitch (P): 0.750"
  • Roller Link Width (W): 0.500"
  • Roller Diameter (D): 0.469"
  • Pin Diameter (O): 0.235"
  • Pin Length (E): 1.000"
  • CL Pin Length (F): 1.059"
  • Plate Thickness (T): 0.094"
  • Plate Height (H): 0.713"
  • Tensile Strength: 9,900 LBS
  • Working Load Rating: 2,090 LBS
  • Weight Per Foot: 0.966 LBS
