28mm Spline Shaft 6-Splines C45 Material - 2000mm
Note:
Custom Cut to Length Chain Also Available
SKU: 64845300-SHAFT
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
28mm Spline Shaft 6-Splines C45 Material - 2000mm Features
28mm Spline Shaft 6-Splines C45 Material - 2000mm Specifications
Our 28mm spline shaft with 6 splines is crafted from high-grade C45 steel and pre-cut to a length of 2000mm. This 28mm shaft meets DIN ISO 14 Standards and is designed for precise torque transmission and alignment, making it ideal for agricultural machinery, drive shafts, and industrial equipment. We also offer a wide range of complementary parts like spline hubs, collars, and clamps for easy assembly. For additional information or a quote on our precision C45 steel 28mm spline shaft with 6 splines in a 2000mm length, contact our customer service team, and we will gladly assist you!
28mm Spline Shaft With 6-Splines Dimensions
- Shaft Diameter (D): 28mm
- Amount of Splines: 6
- Dimension (d): 23mm
- Dimension (b): 6mm
- Length: 2000mm
- Material: C45
- Weight: 3.964 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
- Shaft Diameter (D): 28mm
- Amount of Splines: 6
- Dimension (d): 23mm
- Dimension (b): 6mm
- Length: 2000mm
- Material: C45
- Weight: 3.964 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
