Power Transmission > Shafting > Precision Metric Spline Shaft ISO DIN 14 Standards
20mm Spline Shaft 6-Splines C45 Material - 2000mm
Note:
Custom Cut to Length Chain Also Available
SKU: 64845500-SHAFT
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
20mm Spline Shaft 6-Splines C45 Material - 2000mm Features
20mm Spline Shaft 6-Splines C45 Material - 2000mm Specifications
Our 20mm spline shaft with 6 splines is precision-made from premium C45 steel and comes pre-cut to a length of 2000mm. Compliant with DIN ISO 14 Standards, this 20mm shaft offers excellent torque transmission and precise alignment, making it ideal for use in industrial machinery, agricultural equipment, and drive shafts. With its high durability and performance, this 20mm spline shaft is available with additional parts like spline hubs, collars, and clamps. For additional information or a quote on our precision C45 steel 20mm spline shaft with 6 splines in a 2000mm length, contact our customer service team, and we will gladly assist you!
20mm Spline Shaft With 6-Splines Dimensions
- Shaft Diameter (D): 20mm
- Amount of Splines: 6
- Dimension (d): 16mm
- Dimension (b): 4mm
- Length: 2000mm
- Material: C45
- Weight: 1.911 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
- Shaft Diameter (D): 20mm
- Amount of Splines: 6
- Dimension (d): 16mm
- Dimension (b): 4mm
- Length: 2000mm
- Material: C45
- Weight: 1.911 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
