42mm Spline Shaft 8-Splines C45 Material - 3000mm
Note:
Custom Cut to Length Chain Also Available
SKU: 64848200-SHAFT
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
42mm Spline Shaft 8-Splines C45 Material - 3000mm Features
42mm Spline Shaft 8-Splines C45 Material - 3000mm Specifications
Our 42mm spline shaft with 8 splines is precision-machined from C45 steel and pre-cut to a 3000mm length for ease of use. Built to DIN ISO 14 Standards, this 42mm shaft guarantees accurate torque transmission and proper alignment, making it ideal for industrial applications, agricultural equipment, and drive shafts. Additionally, we stock accompanying components such as spline hubs, collars, and clamps for hassle-free assembly. For additional information or a quote on our precision C45 steel 42mm spline shaft with 8 splines in a 3000mm length, contact our customer service team, and we will gladly assist you!
42mm Spline Shaft With 8-Splines Dimensions
- Shaft Diameter (D): 42mm
- Amount of Splines: 8
- Dimension (d): 36mm
- Dimension (b): 7mm
- Length: 3000mm
- Material: C45
- Weight: 9.30 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
- Shaft Diameter (D): 42mm
- Amount of Splines: 8
- Dimension (d): 36mm
- Dimension (b): 7mm
- Length: 3000mm
- Material: C45
- Weight: 9.30 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
