WD104 Chain Features
WD104 Chain Specifications
WD104 chain features a large and wide pushing area, which gives it the capability of caring a sizable capacity when operating at low to even moderate speeds. WD104 welded steel chain is found in a wide range of applications including; conveyors, forest products, grain handling, heavy duty conveyors, pulp and paper industry, sugar processing, and more! This WD104 drag chain is engineered to be durable, reliable, and high strength. Then manufactured using a select grade of high quality alloy steels to provide a long working life with solid performance.

WD104 Chain Dimensions


WD104 Chain
  • Chain Size: WD104
  • Pitch (A): 6.00"
  • Ultimate Strength: 51,000 LBS
  • Sidebar Height (B): 1-1/2"
  • Sidebar Thickness (C): 3/8"
  • Pin Diameter (D): 3/4"
  • Overall Width (E): 6-3/4"
  • Length Of Bearing (F): 5-3/8"
  • Maximum Sprocket Thickness (G): 4-1/8"
  • Links Per Foot: 2
  • Weight Per Foot: 8.6 LBS


Additionally, we offer a full line of high quality WD104 chain sprockets that exceed in quality, working life, and are supplied at remarkably great prices. We can even supply custom made to order sprockets within a really great lead-time.

WD104 Chain


We can also supply WD104 wing attachments along with the C 1/2 - C4 attachments and even the RR attachments, and have them assembled onto the chain in any configuration needed.

WD104 Chain


For pricing and availability on WD104 chain, sprockets, or attachments please contact us.

Phone: (407) 347-3519
Email: sales@usarollerchain.com
  • Chain Size: WD104
  • Pitch (A): 6.00"
  • Ultimate Strength: 51,000 LBS
  • Sidebar Height (B): 1-1/2"
  • Sidebar Thickness (C): 3/8"
  • Pin Diameter (D): 3/4"
  • Overall Width (E): 6-3/4"
  • Length Of Bearing (F): 5-3/8"
  • Maximum Sprocket Thickness (G): 4-1/8"
  • Links Per Foot: 2
  • Weight Per Foot: 8.6 LBS
