WHX6121 Chain (Drag Chain) Features
WHX6121 Chain (Drag Chain) Specifications
WHX6121 chain is a heavy-duty steel fabricated steel drag chain that features a 27,600 LB working load. This chain is made to handle the most abrasive applications by having hardened surfaces, square edges, and induction hardened pins. Heat treating the surfaces makes the chain have a much higher wear life, while induction hardened pins provide the benefits of a thru-hardened pin while having a higher resistance to abrasion. This WHX6121 chain is engineered and manufactured to provide the maximum strength and the longest wear life. We also offer a full line of high quality WHX6121 sprockets. For more information or to get a quote please contact us and we will be happy to assist you.

WHX6121 Chain Dimensions

WHX6121 Chain (Drag Chain)
  • Chain Size: WHX6121
  • Pitch: 9.00"
  • Overall Width (A): 9.75"
  • Inside Width (L): 3.630"
  • Pin Diameter (G): 1.250"
  • Barrel Diameter (D): 2.50"
  • Sidebar Height (H): 2.50"
  • Sidebar Thickness (T): 1.125"
  • Flight Width: 10" - 30"
  • Rated Working Load: 27,600 LBS
  • Breaking Load: 275,000 LBS
  • Chain Size: WHX6121
  • Pitch: 9.00"
  • Overall Width (A): 9.875"
  • Inside Width (L): 3.630"
  • Pin Diameter (G): 1.250"
  • Barrel Diameter (D): 2.50"
  • Sidebar Height (H): 2.50"
  • Sidebar Thickness (T): 1.125"
  • Flight Width: 10" - 30"
  • Rated Working Load: 27,600 LBS
