Type TXT825 Reducer 25:1 Ratio Size 8 Shaft Mount Reducer

The type TXT825 reducer is a marvel of engineering designed to tackle the most challenging applications both on Earth and in space. This innovative reducer incorporates advanced shaft mount technology, featuring high-precision A.G.M.A case-hardened gearing with a 25:1 reduction ratio. This state-of-the-art gearing system not only extends the operational lifespan of the type TXT825 reducer but also significantly minimizes noise, temperature, and vibration, ensuring optimal efficiency and smooth performance.

Serving as a fundamental component in mechanical systems, the type TXT825 reducer excels by decreasing the input speed from a motor while boosting output torque. This essential function optimizes power transmission, allowing machinery to operate at peak potential with consistent reliability and efficiency.

Constructed with high-precision bearings and a robust shaft, the type TXT825 reducer ensures perfect fitment and prolonged bearing life, even under continuous operation. Its innovative spring-loaded rubber jacketed double-lipped seals are expertly crafted to prevent leakage, with each unit undergoing stringent pressure testing to guarantee flawless, leak-free performance.

Housed in a durable cast iron casing with a specialized anti-corrosive coating, the type TXT825 reducer is built to endure the harshest environments. This sturdy construction ensures exceptional durability and longevity, making it the top choice for industries such as mining, construction, and agriculture, where reliable torque and speed reduction are crucial.

The adaptability of the type TXT825 reducer spans a wide range of applications, including conveyor systems, crushers, mixers, and other heavy machinery. Its versatility and resilience deliver outstanding performance across various sectors, providing the reliability and power necessary to propel complex operations forward.

For comprehensive specifications or to request a quote on the type TXT825 reducer, our knowledgeable customer support team is ready to provide detailed technical assistance and guidance, ensuring you receive the most durable solution tailored to your specific needs.

Type TXT825 Reducer Dimensions

• Part #: VORTXT825
• Ratio: 25:1
• Box Size: 8
• Dimension (L): 20.25"
• Dimension (M): 28.25"
• Dimension (N): 14.03"
• Dimension (F): 2.4375"
• Key: 0.625" X 0.312" X 5.375"
• Maximum Dimension (B): 4-7/16"
• Dimension (C): 2.06"
• Dimension (E): 7.75"
• Dimension (G): 4.31"
• Dimension (W): 3.13"
• Dimension (U): 4.00"
• Dimension (X): 7.04"
• Dimension (V): 5.85"
• Dimension (Q): 7.11"
• Dimension (Y): 2.86"
• Dimension (H): 8.37"
• Dimension (A1): 6.03"
• Dimension (A2): 11.25"
• Dimension (A3): 9.50"
• Dimension (h): 10.13"
• Minimum Dimension (R): 30"
• Maximum Dimension (R): 36"
• Dimension (P): 0.75"
• Dimension (T): 7"
• Gear Box Weight: 655 LBS
