Cast 194C13 Sprocket

Cast 194C13 Sprocket
Cast 194C13 Sprocket



Note: Available as Both Cast or Steel Material
Note: Custom Bore Sizes Available


Product Code: CAST-194C13-SPROCKET
Get a Quote
Call to Order 407-347-3519

Description Technical Specs

This 194C13 sprocket is a 13 tooth cast construction sprocket with a C-Hub (hub on both sides). This sprocket is in the 194 series of engineer class sprockets. It can be supplied with a stock plain bore, finished bore with key-way and set screws, or as an idler sprocket configuration. This sprocket works with chain sizes US90R, 83R, 4215, SR194, GL194, LXS4216, SR194, 14-1/2, 194, U194, 2066, S1194, 1400, and 1594.

194C13 Dimensions


  • Tooth Count: 13
  • Style: C
  • Pitch Diameter: 16.71"
  • Hub Diameter: 6.50"
  • Length Thru Bore: 4.00"
  • Max Bore: 3.62"
  • Tooth Face at Pitch Line: 1.000"
  • Roller Diameter: 2.000"
  • Weight: 64.0 LBS


USA Roller Chain and Sprockets always strives to provide the industry leading service we are known for, as well as competitive and fair prices. Besides sprockets we also offer a full line of roller and engineer class chains, motors with gear reducers, v-belts, pulleys, and a wide variety of other industrial power transmission products. For more information or to get a quote on 194C13 sprockets or any other products, please contact our customer support team and we will be happy to assist you.
About Us
Features
    • Premium Quality Sprocket
    • Extremely Durable
    • Available In Cast or Steel Material
    • Custom Bore Sizes Available
