32mm Spline Shaft 6-Splines C45 Material - 1500mm
Note:
Custom Cut to Length Chain Also Available
SKU: 64843700-SHAFT
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
32mm Spline Shaft 6-Splines C45 Material - 1500mm Features
32mm Spline Shaft 6-Splines C45 Material - 1500mm Specifications
Our precision-engineered 32mm spline shaft with 6 splines is manufactured from durable C45 steel and pre-cut to a 1500mm length. Conforming to DIN ISO 14 Standards, this 32mm shaft ensures efficient torque transmission and proper alignment, making it perfect for use in industrial machinery, drive shafts, and agricultural systems. Additionally, we offer compatible parts like spline hubs, collars, and clamps for a fully integrated solution. For additional information or a quote on our precision C45 steel 32mm spline shaft with 6 splines in a 1500mm length, contact our customer service team, and we will gladly assist you!
32mm Spline Shaft With 6-Splines Dimensions
- Shaft Diameter (D): 32mm
- Amount of Splines: 6
- Dimension (d): 26mm
- Dimension (b): 6mm
- Length: 1500mm
- Material: C45
- Weight: 5.008 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
- Shaft Diameter (D): 32mm
- Amount of Splines: 6
- Dimension (d): 26mm
- Dimension (b): 6mm
- Length: 1500mm
- Material: C45
- Weight: 5.008 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
