Power Transmission > Shafting > Precision Metric Spline Shaft ISO DIN 14 Standards
34mm Spline Shaft 6-Splines C45 Material - 2000mm
Note:
Custom Cut to Length Chain Also Available
SKU: 64845900-SHAFT
Item is in stockOnly 0 left in stockItem is out of stock
Item is unavailable
Login to Request a Quote
34mm Spline Shaft 6-Splines C45 Material - 2000mm Features
34mm Spline Shaft 6-Splines C45 Material - 2000mm Specifications
Our 34mm spline shaft with 6 splines is made from premium C45 steel and pre-cut to a standard length of 2000mm. Engineered to meet DIN ISO 14 Standards, this 34mm spline shaft is designed for precise torque transmission and alignment, making it ideal for industrial machinery, drive shafts, and agricultural equipment. We also offer a variety of complementary parts, such as spline hubs, collars, and clamps for easy assembly. For additional information or a quote on our precision C45 steel 34mm spline shaft with 6 splines in a 2000mm length, contact our customer service team, and we will gladly assist you!
34mm Spline Shaft With 6-Splines Dimensions
- Shaft Diameter (D): 34mm
- Amount of Splines: 6
- Dimension (d): 28mm
- Dimension (b): 7mm
- Length: 2000mm
- Material: C45
- Weight: 5.816 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
- Shaft Diameter (D): 34mm
- Amount of Splines: 6
- Dimension (d): 28mm
- Dimension (b): 7mm
- Length: 2000mm
- Material: C45
- Weight: 5.816 Kg/ Meter
- Length Tolerance: 0.8mm/ Meter
- Maximum Torsion: 0.5mm/ Meter
